Carrier TSTATCCPS101 - Front Panel Description; LCD Display and Controls

Front Panel
Page 2
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
Su
Backlit LCD Display
Warmer or + Button
Cooler or - Button
Mode Button
Heat or Cool Indicator
Red = Heat, Green = Cool
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
S
SET CLOCK
PROGRAMVACATIONOUTSIDEFAN MODE
Programmable
Thermostat
FAN
PROGRAM
BACKLIGHT
SET CLOCK
EMERGENCY HEAT
