Carrier TSTATCCREC01 - Connections & Switches

Connections & Switches - Setting House Code
Page 5
W2
Y2
R
W1
O
B
Y1
GC
11
22
44
88
1616
3232
EHEH
HPHP
ONON
OFFOFF
Antenna
Terminals for
Connection to
HVAC
Dip
Switches
Circuit Board
Rear Housing
11
22
44
88
1616
3232
EHEH
HPHP
ON
OFF
11
22
44
88
1616
3232
EHEH
HPHP
ON
OFF
Add all ON switches to
arrive at HOUSE CODE
number. All thermostats
communicating with this
receiver must have the
same House Code #.
All # switches off = 0
ON Indicator
Example:
House Code 10,
2+8=10
O / BO / B
O / BO / B
