Carson Reflex Wheel Pro LCD - Equipment for Combustion Engine; External Transmitter View and Battery Installation

22
GB
CARSON Reflex Wheel Pro LCD 2,4 GHz 50 050 0033
Install the batteries
1. Remove the battery compartment cover.
2. Replace the used batteries with new AA
size batteries.
Please replace batteries when the power
indicator blinks or the buzzer beeps.
4 Batteries
Equipment for Combustion Engine
Receiver batteries and two servos are not included in the kit.
Receiver
Regard the
form of the
connector!
Receiver switch
Receiver battery case, NiMH-
batteries item No. 50 060 9000
are recommended
Steering servo Channel 1
(not included)
Throttle servo Channel 2
(not included)
Servo Channel 3
(not included)
ATTENTION
When connecting the servo to the receiver
always regard the form of the connector! The
black wire is facing outward!
External View of Transmitter
