Carson Reflex Wheel Pro LCD User Manual

23
GB
CARSON Reflex Wheel Pro LCD 2,4 GHz 50 050 0033
Function
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
B/C: Power connector
2,4 GHz antenna
LCD display
+/- button
SEL/CH
button
ST D/R
button
TH D/R
button
Power
Grip handle
Battery box
Steering wheel
Throttle
trigger
Throttle trim
Steering trim
Switch
Fail safe set
Switch for
3. channel
Charger
socket
Throttle rate
adjuster
The ratio of throttle operation to break/revers
operation can be switched in two steps, either 50:50
or 70:30. The last is to be used preferably for gas
powerec cars or races.
Throttle rate
adjuster
Throttle Rate Adjuster
