25 // GB
Video
MOUNTING THE CAMERA ONLY VERSION „SPY“ 500507100
INSERT THE SD CARD ONLY VERSION „SPY“ 500507100
PHOTO/VIDEO ONLY VERSION „SPY“ 500507100
Using the enclosed screws (4), mount the
vibration-absorbing camera mount on the
undersideofthequadcopter.Nowthecamera
module can be carefully mounted on the holder
(observe the direction of the arrows).
Finally plug the connection cable for the video
module into the model. (See illustration)
Taking photographs:
Press the photo button on the transmitter to take an individual
picture (photo).
The photo symbol is displayed briefly on the transmitter screen.
You will also see the status LED on the copter change briefly from
green to red.
Video recording:
Press the video button on the transmitter to record video clips.
The video symbol is displayed on the transmitter screen.
You will also see that the status LED on the copter flashes red
during recording.
Reading the SD card:
Switch the camera off and then remove the SD card.
Now you can view and edit the images and video footage on the
computer.
Push the micro SD card (not included) into the card slot as shown
in the illustration.
The card clicks into place. If you push the card a second time, it
slides back out again. The flight battery must not be connected to
the model when inserting or removing the SD card.
Screw
