Carter INTERCEPTOR GTR 250 - Fig.5 L Crank Case

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
3
1
1
1
1
2
1
1
1
1
1
3
2
4
7
1
REF. QTY DESCRIPTION
PART NO.
FIG.5 L CRANK CASE
Fig.5 L CRANK CASE
8213-3030
8213-3031
8240-3201
8213-3032
8213-3033
8213-3034
8200-3193
8257-3014
8200-3404
8200-0193
8200-0591
8200-3507
8100-0160
8100-0162
8200-3112
8200-3114
8213-3035
L Crank Case Comp
Setting Plate
Mission Breather Tube
Drain Tube Assy.
Tube Clip-E5
Change SW. Assy.
Cylinder Stud Bolt B
Spring, Fixed Catch
Screw, Fixing
Drain Plug Bolt 12mm
Drain Plug Washer 12mm
Drain Plug Washer 14mm
Flange Bolt SH 6x12
Flange Bolt SH 6x18
Flange Bolt SH 6x50
Flange Bolt SH 6x70mm
Sted Ball #12
5
