Carter INTERCEPTOR GTR 250 - Crank Shaft

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
REF. QTY
DESCRIPTION
PART NO.
FIG.9 CRANK SHAFT
Fig.9 CRANK SHAFT
8213-3054
8213-3055
8213-3056
8213-3057
8213-3058
8213-3059
8213-3060
8213-3061
8213-3062
8213-3063
8213-0095
8222-3012
8200-3704
8222-3017
8222-3010
Crank Shaft Comp
Piston Ring Set
Piston
Piston Pin
Connecting Rod
Conn. Rod Assy.
Balance Shaft Drive Gear
R Crank Side Plate
Crank Pin
Piston Pin Clip 17mm
Woodruff Key 25x14x4
Connecting Rod Bearing PK32x41x17.8
Oil Seal TC 27x42x7
Radial Ball Bearing 6207
Radial Ball Bearing TMB306JR2C3
9
