Carter INTERCEPTOR GTR 300 - Carburetor Assembly

1
2
3
4
5
6
7
8
9
10
1
1
1
2
2
1
1
1
1
1
REF. QTY
DESCRIPTION
PART NO.
FIG.17 CARBURETOR ASSEMBLY
Fig.17 CARBURETOR ASSEMBLY
8213-3113
8213-3114
8200-3603
8100-0206
8100-0164
8213-3115
8213-3116
8213-3117
8213-3118
8240-3001
Carb. Assy.
Inlet Pipe Assy.
O-Ring 34x2.0
Flange Nut 6mm
Flange Bolt SH 6x22
Carb. Needle Fixing Set
Carb. Screw Fixing Set
Carb. Float Fixing Set
Carb. F.C.B Fixing Set
Carb. Gasket Fixing Set
17
