SERVICE INFORMATION
J. Front Wheel Replacement
Do not disassemble the castle nuts when you replace the front wheels.
It is only necessary to remove the four 4 lug nuts to remove the wheel.
Tighten the nuts after replacing the wheels.
K. Rear Wheel Replacement
Do not disassemble the castle nuts when you replace the rear wheel and hub assembly.
Remove the cotter pin and the 24mm nut. Then slide off wheel and hub assembly.
It is only necessary to remove the four 4 lug nuts to remove the wheel by itself.
