Cascade 55K Installation Instructions

8
FP1718.eps
^
&
9
3
3
5
7
6
4
1
2
3
*
0
8
%
9
$
@
#
!
#
9
(
9
120K, 150K & 165K Solenoid Control Kit
REF QTY PART NO. DESCRIPTION REF QTY PART NO. DESCRIPTION
6805088 Solenoid Control Kit–12V 9 1 6050638
Fitting ● ■
6805091 Solenoid Control Kit–24V 10 1 617917
Fitting, 4-4 ●
6805092 Solenoid Control Kit–36V 11 1 6805079 Hose, 34.0 in. (870 mm)
6805093 Solenoid Control Kit–48V 12 1 6050052 Hose, 20.0 in. (510 mm)
1 1 6090116 Guard 13 2 6805080 Hose, 31.0 in. (795 mm)
2 1 6054448 Mounting Bar 14 1 669432 Diode
3 6 787372 Capscrew, M8 x 25 15 1 6008166
Solenoid Cartridge
■
4
1 6064490 Solenoid Valve Assembly–12V
16
1 6860494
Solenoid Coil–12V
■
1 6064502 Solenoid Valve Assembly–24V 1 6860576
Solenoid Coil–24V
■
1 6064503 Solenoid Valve Assembly–36V 1 6859258
Solenoid Coil–36V
■
1 6064504 Solenoid Valve Assembly–48V 1 6860663
Solenoid Coil–48V
■
5 1 768991
Roll Pin, 5 x 10 mm
■
17 1 6126457 Service Kit
6 2 768785 Capscrew 18 1 6052237
Valve Body
■
7 1 6050411
Manifold ●
19 2 665595 Decal
8 1 201671
Fitting ●
● Included in Manifold Assembly 6050615
■ Included in Solenoid Valve Assembly, Item 4
