CASE CONSTRUCTION CX210D - ROPS judgment

INTRODUCTION
Safetyrules–ROPSjudgment
1.Purpose
JudgewhetherornotthemodeliscompliantwithROPSbytheROPScriteria.
CompliancewithROPSishighlydependentonitsdeadweightandboom.
ThemodelhaspassedtheROPStestforitsdeadweightwithallselectableoptionsinstalled(asof2014).
However,thejudgmentisrequiredbecauseitsdeadweightorboompositionmaygobeyondtheassumptionde-
pendingonderivativeororderconditions.
2.ROPScriteria
Weight
Foreachclass,thefollowingweightshallnotbeexceeded.
Iftheweightisexceeded,acabmaybecomedamagedincaseofarollover,causingtheoperatortodieorbecome
severelydisabled.
Itisnotapplicablebeyondthecriterion.
TheROPS-compliantmodelshallnotexceedtheweightshowninthetable.
(ThefollowingweightisshownonthedecalintheROPScab.)
Grossbodyweight
Class
CX130D
CX160D
20500kg(45194.76lb)orless
CX180D
CX210D
CX230D
CX250D
32000kg(70547.92lb)orless
CX300D
Boomposition
Warning
•
Ifyoumakesuchmodicationaslowerstheboomposition,ROPSisnotapplicable.
•
Consultationwithusisrequiredwheneveritisassumedthattheboompositionisloweredbymodication.
•
Therangeofchangeintheboompositioncannotbedetermineduniformly.
SMIL14CEX2001EA1
(a)Groundpoint
Itisnotapplicableifthepositionoverlappingwithacabonthesideview(mark*inthegure)isloweredsignicantly
ascomparedwiththestandardmodel(standardarm),withinthemaximumdiggingradiuswiththebuckettiponthe
surfaceoftheground.
