TECHNICAL MANUALS
Manuals are available from your Dealer for the operation, service, and repair of your machine.
Contact your Dealer for assistance in obtaining the manuals for your machine. Your Dealer can expedite your order for
Operator’s Manuals, Parts Catalogs, Service Manuals, and maintenance records.
Always give the Machine Name, Model, and P. I.N. (Product Identification Number) or S. N. (Serial Number) of your
machine so your Dealer can provide the correct manuals for your machine.
THIS SAFETY ALERT SYMBOL INDICATES IMPORTANT SAFETY MESSAGES IN THIS MANUAL.
WHEN YOU SEE THIS SYMBOL, CAREFULLY READ THE MESSAGE THAT FOLLOWS AND BE ALERT
TO THE POSSIBILITY OF DEATH OR SERIOUS INJURY.
Safety Decals on this machine use the words Danger, Warning, or Caution, which are defined as follows:
● DANGER: Indicates an immediate hazardous situation that, if not avoided, will result in death or serious injury.
The color associated with Danger is RED.
● WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or serious
injury. The color associated with Warning is ORANGE.
● CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe practices. The color associated with Caution is YELLOW.
If Safety Decals on this machine are ISO two panel Pictorial, decals are defined as follows:
● The first panel indicates the nature of the hazard.
● The second panel indicates the appropriate avoidance of the hazard.
● Background color is YELLOW
● Prohibition symbols such as and if used, are RED.
STOP
IMPROPER OPERATION OF THIS MACHINE CAN CAUSE DEATH OR SERIOUS INJURY. BEFORE USING THIS
MACHINE, MAKE CERTAIN THAT EVERY OPERATOR:
❷
Is instructed in safe and proper use of the machine.
❷
Reads and understands the Manual(s) pertaining to the machine.
❷
Reads and understands ALL Safety Decals on the machine.
❷
Clears the area of other persons.
❷
Learns and practices safe use of machine controls in a safe, clear area before operating this machine on a job
site.
It is your responsibility to observe pertinent laws and regulations and follow instructions on machine operation and
maintenance.
CALIFORNIA
PROPOSITION 65 WARNING
Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects,
and other reproductive harm.
Battery post, terminals and related accessories contain lead and lead compounds. Wash hands after handling.
S2PV00033ZE01 NACX27B Tier 4 Compact Crawler Excavator
01Nov 08
First Edition
REVISION HISTORY
RemarksIssue Issue Date Applicable Machines
This unit first became available 11-2008
Any use of editorial or pictorial content is strictly prohibited without express written permission from
CNH America, LLC. Racine, WI 53403 U.S.A..
CNH America, LLC reserves the right to make improvements in design or changes in specifications at any time without incurring any
obligation to install them on units previously sold.
All data given in this publication is subject to production variations. Dimensions and weights are only approximate. Illustrations do not
necessarily show products in standard condition. For exact information about any particular product, please consult your Dealer
