Item Name Item Name Item Name
1 Engine 14 Canopy 27 Swing cylinder
2 Hydra ulic pump 15 Right side cover 28 Boom cylinder
3 Muffler 16 Guard 29 Boom
4 Control valve 17 Engine hood 30 Arm cylinder
5 Hydraulic oil tank 18 Counterweight 31 Arm
6 Fuel t ank 19 Swing bearing 32 Bucket cylinder
7 Swing motor 20 Rubber track shoe 33 Idler link
8 Swivel joint 21 Idler Assembly 34 Bucket link
9 Air cleaner 22 Lower r oller 35 Bucket
10 Battery 23 Upper roller 36 Light
11 Radiator 24 Travel motor 37 Fuel cooler
12 Oil filter 25 Dozer cy linder
13 Reserve tank 26 Dozer
Წ
2.1 CO MPO NENTS NAME
㨇
2. SPECIFICATIONS
㨉
2-3
