3-SPECIFICATIONS
Arm
3.10m(122.05in)
Boom
5.35m(210.63in)
(A)Maxdiggingreach8.93m(351.57in)
(B)Maxdiggingreachatgroundlevel(GL)8.83m(347.64in)
(C)Maxdiggingdepth6.71m(264.17in)
(D)Maxdumpheight7.49m(294.88in)
(E)Maxdumpdistance4.64m(182.68in)
(F)Maxworkingheight9.26m(364.57in)
(G)Reachatmaxworkingheight3.99m(157.09in)
(H)Minequipmentswingradius1.76m(69.29in)
(I)Heightatminequipmentswingradius7.07m(278.35in)
(N)Maxdiggingdepthonaverticalface5.24m(206.30in)
(O)Reachatmaxdiggingdepthonaverticalface2.00m(78.74in)
(P)Maxat-bottomedtrenchingdepth6.38m(250.98in)
(Q)Distanceofat-bottomedtrench6.01m(236.61in)
(R)Flat-bottomedtrenchreferencelength2.44m(96.06in)
(S)Swingtailradius1.35m(53.15in)
(T)Maximumbladelift0.44m(17.32in)
(U)Maximumbladedepth0.28m(11.02in)
NOTE:thedimensionsoftheworkingrangearedenedbasingonthetworeferencelines(GL)(groundlevel)and
(CL)(centerline,i.e.rotationaxisofthemachine).Allthedimensionsrelatedtothe(GL)aredenedwiththegrousers
indentedintotheground.
