Productidentication
TheCX85DSRLRisacrawlerhydraulicexcavator.Itconsistsofanundercarriagettedwithtracksandaturntable
bearingwhichsupportstheupperstructureframe.Theupperstructureframesupportstheattachment,atthefrontend
ofthemachine,plustheengine,hydraulicsandcab.Whentheoperatorworksthecontrols,theengine-drivenpump
delivershydraulicuidtothecontrolvalves.Thecontrolvalvesdistributethehydraulicuidtothevariouscylinders
andhydraulicmotorsemployed.Acoolingsystemmaintainsthehydraulicuidatnormaloperatingtemperature.
SMIL19CEX2808EA1
CX85DSRLR(LongReach)
Whenorderingparts,obtaininginformationorassistance,alwayssupplyyourCASECONSTRUCTIONDealerwith
thetypeandserialnumberofyourmachineoraccessories.Writethefollowinginthespacesbelow:thetype,serial
numberandyearofmanufactureofyourmachine,accessoriesandtheserialnumbersofthevarioushydraulicand
mechanicalcomponents.
Machine
(1)Designation/Model
HydraulicExcavatorCX85DSRLR
(2)ProductIdenticationNumber(PIN)
(3)YearofConstruction
(4)ModelYear
(5)Maximumoperatingmass
(theweightshownonthemanufacturer'splateisthevalue
usingtheheaviestcongurationandthatitdoesnotal-
wayscorrespondtothetransportconguration)
(6)EnginepowerISO14396
