Case IH AXIAL-FLOW 8230 User Manual

INTRODUCTION
72308230,9230
Totalsystemcapacity
57l(15USgal)
Pumptype
Closedcenterloadsensing
Pumpcapacity
160l/min(42USgpm)
Maximumpressure
21029kPa(3050psi)
SteeringValveHydrostaticLoadSense
Maximumpressure
16500kPa(2390psi)
HYDROSTATICSYSTEM
Pumpcapacity(cc/rev)117(125w/planetarynaldrives)
125
Motorcapacity(cc/rev)
Fixeddisplacement
107(125w/planetarynaldrives)
125
Variabledisplacement140
Maximumpressure,forward46484kPa(6742psi)
Maximumpressure,rearward
46484kPa(6742psi)
CAB
Cabtype
Deluxe
OperatorSeat
AirRide
InstructionalSeat
Padded
Airconditioning
ATC
Heating
ATC
Poweradjustandheatedmirrors
Opt.
Wipers
Std.
WindshieldWasher
Std.
TRACTION
Transmission4speedhydrostatic
Oilcapacity19l(5USgal)
Differential16/71(20/61w/planetarynaldrive)20/61
DifferentialLockOpt.
Steeringaxle
Adjustable
PoweredRearAxletype
Camlobeswivelmotorsteerablewheeldrives,availableintwo-speed
version
Brakes
Servicesbrakestype
Manualdualcaliperdisc
Parkbraketype
Springapplied,hydraulicallyreleased
Finaldrives
Type
Bullgear/Opt.Planetary
Planetary
Ratio
11:111(1:13.09w/planetarynal
drive)
1:13.09
Weight(approximate)
723082309230
Withsingledrivetiresand
withoutPowerGuideAxle
(PGA)
17280kg(38095lb)17735kg(39100lb)
4804083715/08/2017
24
