INTRODUCTION
Productidentication-Machineorientation
Todetermine"left-hand"(LH)and"right-hand"(RH)side,standattherearofthemachineandfacethenormaldirection
oftravel.
NOTE:Thearrowindicatesthenormaldirectionoftravel.
NHIL12AF02754AA1
Left-handside
NHIL12AF02758AA2
Right-handside
NHPH12AF03454AA3
Front
NHPH12AF03455AA4
Rear
4804083715/08/2017
31
