Engine-Aircleanersandlines
9.Loosenclamp(1)attheairplenum(2).
10.Carefullyworktheaircleaneroffoftheplenumand
removetheaircleanerandsetaside,outoftheway
andinasafeplace.
NHPE13AF00448AA8
11.Ifremovingtheairplenum(1),removethesixange
bolts(2)securingtheairplenumtothecoolerbox.
NHPE13AF00539AA9
Nextoperation:
Airintakesystem-Installto7230(10.202)
