Case IH AXIAL-FLOW 8230 User Manual

Engine-Fuelinjectionsystem
CylinderSolenoidFaultCodes
3L-38
E1583-03–Cyl.#3SpecicErrors-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1590-02–Cylinder3-ShortCircuitLow/High-DataincorrectTroubleshooting
procedure:Injectioncontrol-Incorrectvalue(55.010)
E1590-03–Cylinder3-ShortCircuitLow/High-Shortedtohighsource
Troubleshootingprocedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1590-12–Cylinder3-ShortCircuitLow/High-Badintelligentdevice
Troubleshootingprocedure:Injectioncontrol-Badintelligentdevice(55.010)
E1596-02–Cylinder3-OpenLoad-DataincorrectTroubleshootingprocedure:
Injectioncontrol-Incorrectvalue(55.010)
E1596-03–Cylinder3-OpenLoad-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
4L-35
E1584-03–Cyl.#4SpecicErrors-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1591-02–Cylinder4-ShortCircuitLow/High-DataincorrectTroubleshooting
procedure:Injectioncontrol-Incorrectvalue(55.010)
E1591-03–Cylinder4-ShortCircuitLow/High-Shortedtohighsource
Troubleshootingprocedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1591-12–Cylinder4-ShortCircuitLow/High-Badintelligentdevice
Troubleshootingprocedure:Injectioncontrol-Badintelligentdevice(55.010)
E1597-02–Cylinder4-OpenLoad-DataincorrectTroubleshootingprocedure:
Injectioncontrol-Incorrectvalue(55.010)
E1597-03–Cylinder4-OpenLoad-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
5
L-37
E1586-03–Cyl.#6SpecicErrors-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1593-02–Cylinder6-ShortCircuitLow/High-DataincorrectTroubleshooting
procedure:Injectioncontrol-Incorrectvalue(55.010)
E1593-03–Cylinder6-ShortCircuitLow/High-Shortedtohighsource
Troubleshootingprocedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1593-12–Cylinder6-ShortCircuitLow/High-Badintelligentdevice
Troubleshootingprocedure:E1593-12-Cylinder6-ShortCircuitLow/High-Bad
intelligentdevice(55.010)
E1599-02–Cylinder6-OpenLoad-DataincorrectTroubleshootingprocedure:
Injectioncontrol-Incorrectvalue(55.010)
E1599-03–Cylinder6-OpenLoad-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
6L-39
E1585-03–Cyl.#5SpecicErrors-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1592-02–Cylinder5-ShortCircuitLow/High-DataincorrectTroubleshooting
procedure:Injectioncontrol-Incorrectvalue(55.010)
E1592-03–Cylinder5-ShortCircuitLow/High-Shortedtohighsource
Troubleshootingprocedure:Injectioncontrol-ShortcircuittoB+(55.010)
E1592-12–Cylinder5-ShortCircuitLow/High-Badintelligentdevice
Troubleshootingprocedure:Injectioncontrol-Badintelligentdevice(55.010)
E1598-02–Cylinder5-OpenLoad-DataincorrectTroubleshootingprocedure:
Injectioncontrol-Incorrectvalue(55.010)
E1598-03–Cylinder5-OpenLoad-ShortedtohighsourceTroubleshooting
procedure:Injectioncontrol-ShortcircuittoB+(55.010)
Schematicreferences:
9.0LEngine-Wiringharnesses-Electricalschematicsheet05(55.100)
10.3LEngine-Wiringharnesses-Electricalschematicsheet04(55.100)
4804083715/08/2017
10.3[10.218]/8
