Engine-Fuelinjectionsystem
KeySwitchedpowerfromS-02ConnectorX193pin40
Engineground
ConnectorX193pins5,,6,10,11
ModuleControlOutput
ControlsignaltoL-34(cyl1)ConnectorX515pin4
ControlsignaltoL-36(cyl2)ConnectorX515pin11
ControlsignaltoL-38(cyl3)ConnectorX515pin5
ControlsignaltoL-35(cyl4)ConnectorX515pin3
ControlsignaltoL-39(cyl5)ConnectorX515pin1
ControlsignaltoL-37(cyl6)ConnectorX515pin2
OutputDevicePowerSource
FuelActuator1L-34
ControlsignalfromA-01ConnectorX376pin2
SignalgroundfromA-01ConnectorX376pin1
FuelActuator2L-35
ControlsignalfromA-01ConnectorX377pin2
SignalgroundfromA-01ConnectorX377pin1
FuelActuator3L-36
ControlsignalfromA-01ConnectorX378pin2
SignalgroundfromA-01ConnectorX378pin1
FuelActuator4L-37
ControlsignalfromA-01ConnectorX379pin2
SignalgroundfromA-01ConnectorX379pin1
FuelActuator5L-38
ControlsignalfromA-01ConnectorX380pin2
SignalgroundfromA-01ConnectorX380pin1
FuelActuator6L-39
ControlsignalfromA-01ConnectorX381pin2
SignalgroundfromA-01ConnectorX381pin1
Components/DevicesAssociatedwithOutputDeviceOperation
EngineFlywheelRPMSensorB-05
ControlsignalfromA-01ConnectorX519pin1
SignalgroundfromA-01ConnectorX519pin2
EngineCamshaftRPMSensorB-07
ControlsignalfromA-01ConnectorX518pin1
SignalgroundfromA-01ConnectorX518pin2
CoolantTemperatureSensorB-44
ControlsignalfromA-01ConnectorX373pin1
SignalgroundfromA-01ConnectorX373pin2
4804083715/08/2017
10.3[10.218]/10
