Engine-Fuelinjectionsystem
Commonrail-Remove
1.Disconnecttheharnessfromtherailpressuresensor
(1).
NHVM17ENG0223AA1
2.Loosenthehighpressurefuelpipeconnectionsateach
injector(2).
NHVM17ENG0224AA2
3.Disconnectallofthehighpressurefuelpipes(3)and
therailreturnpipe(4)fromtherail.
NHVM17ENG0225AA3
4.Removetheboltsandspacers(5)thatsecuretherail
tothecylinderhead.
NHVM17ENG0226AA4
4804083715/08/2017
10.3[10.218]/12
