16
generator components
Grounding Ter-
minal
It is to make the generator realize safe grounding.
As to the grounding method, refer to the Page 19.
Make sure unobstructed grounding before use.
Handrail Pipe
After lifted up, the pipe, with self-locking structure,
can be used to move the generator.
Starter Grip
It is to start up the engine. For the method, refer to
Page 22.
Air Cleaner
It is to filter air and remove impurities in the air
entering cylinder. As to the maintenance method,
refer to Page 30.
Fuel Switch
It is to control fuel’s entering into the engine via the
fuel tank. During non use of the generator, leave
the switch off.
Chock Valve
It is to control air flow into the cylinder when
starting up the engine. As to the operating method,
refer to Page 22.
Muffler
It is to eliminate noise during equipment operation,
and discharge high temperature exhaust of
engine’s combustion. Do not touch it to avoid
burning.
Timer
The Timer records the running time of the
generator. Press conversion key to convert
between cumulative timing and single timing. The
Timer will prompt to change the engine oil at 20
hours for the first time and then prompt every 100
hours; and will prompt to clean the air cleaner
every 50 hours.
