Case IH BC12000ER - Maintenance: Valve Clearance; Valve Clearance Adjustment Procedure

30
maintenance
VALVE CLEARANCE
Remove the cylinder head cover and measure the valve clearance with
the feeler gauge. The clearances are 0.03~0.05mm for the inlet valve and
0.05~0.07mm for the outlet valve.
(should be conducted by a professional person)
