Engine-Engineandcrankcase
Installthecamshaftwiththethreeholes(viewedfromthe
front)inthe9,12and3o’clockposition.
NOTE:Donottrustthebackofthecamforpositioning.
RAIL15TR00380BA22
Installthecamshaftgearasshown.
InMagnum™tractors,thecamdrivemustbeinstalled
withthethreephonicwheelmountingholesmakingan
arrowpointingtotheright.Ifthisisnotdone,thephonic
wheelwillnotbeabletobetimed.
Theslottedholesmustbecenteredonthecamshaftbolt
holestomakeneadjustmentstothecamlaterinthis
process.
Installtheboltsandtighten,butdonottorqueyet;theywill
beloosenedlaterinthisprocedure.
RAIL15TR00378BA23
5143149922/02/2018
10.1[10.001]/17
