Engine-Engineandcrankcase
Phonicwheeladjustment
Usingthephonicwheeltimingfork(specialtool
380000151)withtheywheellockedintheDposition,
installthephonicwheelsothetimingforkengagesthe
phonicwheeltoothwiththe“^”mark.Tightenthephonic
wheelretainingboltstothespeciedtorque.
RAIL15TR01372BA27
Adjustingthevalvelash
Flywheel
Cylinder
B1
A4
C
2
B6
A3
C
5
•
ThevalvescanonlybeadjustedwhenthepistonisatTDCring.
•
RotatetheenginecounterclockwisetotheBhole(therstholeafterthehole
withthedoublemark).Usethetimingpintolocktheywheel.
•
Nowadjustthevalvesoncylindernumber1.
•
Usethecharttothelefttodeterminewhichholetousetoadjustthevalves.
5143149922/02/2018
10.1[10.001]/20
