SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--24
INTERNATIONAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilised on the instruments,
controls, switches, and fuse box. The symbols are shown below with an indication of their meaning.
Engine cold
start aid
Turn signals Parking brake Fast steer
Alternator
charge
Turn signals
trailer 1
Brake lock
Draft
control
Fuel level
Turn signals
trailer 2
Trailer brake
Position
control
Engine speed
(rev min x 100)
Windscreen
wiper
Check parking
brake
Rear hitch
lower
Hours recorded
Windscreen
washer
Exhaust brake
Rear hitch
raise
Engine oil
pressure
Rear screen
wiper
Brake fluid
level
Rear hitch
float
Engine coolant
temperature
Rear screen
washer
N
Neutral
Rear hitch
height limit
Coolant level
Heated rear
screen
Fast or high
setting
Front hitch
height limit
Engine air filter
blocked
Heated front
screen
Slow or low
setting
PTO
Tractor lights Horn
Creeper
speeds
Remote valve
retract
Headlamp high
beam
Heater
temperature
control
Forward
direction
Remote valve
extend
Headlamp
dipped beam
Blower fan
Reverse
direction
Remote valve
float
Tractor
sidelamps
Air conditioning
control
% wheel slip
Warning
STOP
Work lamps Variable control Differential lock Attention!
Hazard warning
lamps
Radio 4WD engaged
Malfunction
See Operators
manual
Flashing
beacon
KAM
Keep alive
memory
Front
suspension
locked
Malfunction
See Operators
manual
