Case 1021F - Windows

3-CONTROLSANDINSTRUMENTS
Windows[60631719]
Windowlatch
Thewindowcanbekeptpartiallyopenbyliftingthehold
latchandslidingitbackonthelatchpinuntiltheholdlatch
locksinthelatchpin.
Thewindowmaybeopenedandlockedagainstthesideof
thecab.Toopenandlockthewindow,pulltheholdlatch
towardtherearofthecabwhenthewindowispartially
open.Thiswillunlatchthewindowandallowthewindow
toswingbackagainstthecabandlockinplace.
RCPH10WHL143BAL1
1.Lifttoopen
RCPH10WHL142BAL2
2.Latchpin
3.Holdlatch
Toreleasethewindowfromthefullopenposition,pullon
thewindowreleaseintherighthandrearcornerofthe
cab.
RCPH10WHL139BAL3
