Case 1021F - Support Strut for Loader Lift Arm - Support Strut and Service Link

2-SAFETYINFORMATION
Supportstrutforloaderliftarm-Supportstrutandservicelink[60622288]
DANGER
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplywillresultindeathorseriousinjury.
D0084A
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.
Supportstrut
1.Emptytheloaderbucket,raisetheloaderliftarmsto
approximately2.1m(7ft)andstoptheengine.Re-
movethesupportstrutfromthestoragepositionby
removingtheretainingbolt.
LEIL12WHL0006BA1
2.Placethesupportstrutontothecylinderrodwithguide
locktabontopofcylinderandpointingtowardthe
bucket.Installtheretainingboltentirelyintothesup-
portstrutusingallthreads.Slowlylowertheliftarms
ontothesupportstrut.
RCPH10WHL061BAL2
2-14
