1650K
TRANSMISSION/
TORQUE
CONVERTER
0-7
TABLES
OF
TECHNICAL
DATA
Torque converter - transmission group
Transmission pump delivery
(at max. power speed)
Converter pump
(at max. power speed)
Transmission filters
Pressure relief valve
Suction
Delivery
Pressure relief valve (at flow of 10 It/min)
Transmission pressure (at flow of 10 It/min)
Transmission pressure (at flow of 70 It/min)
Safety lever valve
Controls:
Joystick, Shift up-down slider button.
Pump combined with converter
powering
oil
pump and oil scavenger
pump
70 It/min (17 bar)
53 It/min
(3
bar)
Metal mesh and magnetic
rod,
filtering
capacity 100 micron,
Cartridge
type
(SPIN ON) with
paper
cartridge
and
by-pass
valve,
filtering
capacity 25 micron.
Mounted
on
converter cover
10
± 0.5 bar
13.75
± 0.5 bar
17.0
± 0.5 bar
In
the locked position,
it
prevents the shifting
of gears and the starting of the engine and
it
engages the parking brake.
FWD
& REV actuated thru pressure switches on the joystick.
Selection of operating mode -
AS
-AL
Description
of
auto mode
automatic
AUTO-
SHIFT
automatic AUTO - LOW
AL Downshifting when the engine drops to a pre-determined speed.
AS It provides the operator with the pre-selection of the 1st gear forward and 2nd gear
reverse when shifting direction.
Propeller shaft With two universal joints and sliding shaft
Nominal length 265.5 mm
