INTRODUCTION
3.Refertothedecalontheinteriorsideofthepanelcover
forfuse,relay,and/ordiodefunctions.
RCPH10TLB310AAF4
FrontconsoleECUfuseandrelay
1.Removethecoverfromthesteeringcolumnshroud.
RCPH11TLB012BAD5
Fuseorrelay
reference
Designation
(1)ECUB+relay
(2)ECUB+20Afuse
(3)ECUB+7.5Afuse
(4)LAMBDASENSORB+7.5Afuse
RAPH12TLB0016BA6
4819454220/11/2017
12
