Case 580N - Front Console Fuse and Relay Panel

INTRODUCTION
Frontconsolefuseandrelaypanel
PowerShuttlePowershift
47747127_A5
Fuseicondenitions
Symbol
Function
Hazardlights
CrankcaseVentilation(CCV)heater
UnswitchedBattery+toSCRpumpmodule
UnswitchedBattery+toSCRheatvalveandpump
UnswitchedBattery+toT4Bandureasensors
By-passrelaybattery+
AUXmainrelay,electricvalve,by-passrelaycoilpower
ECUBattery+Band+C
ECUBatteryvoltage
