Case 580N - Basic Instructions - Support Strut for Loader Lift Arm

INTRODUCTION
Basicinstructions-Supportstrutforloaderliftarm
WARNING
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplycouldresultindeathorseriousinjury.
W0230A
Engagetheloaderarmsupportstrut:
1.Emptytheloaderbucket.
2.Raisetheloaderliftarmstothemaximumheight.
3.Shutdowntheengine.
4.Removetheretainingpin.
RAIL14TLB0846BA1
5.Lowerthesupportstrutontothecylinderrod.
6.Installandsecuretheretainingpin.
RAIL14TLB0847BA2
4819455820/10/2017
38
