INTRODUCTION
NOTICE:Avoidexcesspressureontheloaderarmcylin-
der.Donotstarttheenginetolowertheloaderarmonto
thesupportstrut.
7.Movetheloadercontrollevertorelievehydraulicpres-
sure.Thebottomofthesupportstrutwillbraceagainst
thetopofthecylinderbase.
RAIL14TLB0859BA3
Disengagetheloaderarmsupportstrut:
1.Raisetheloaderarmssothattheendofthesupport
strutnolongeragainstthecylinder.
2.Shutdowntheengine.
RAIL14TLB0859BA4
4819455820/10/2017
39
