Case 580N - STC Disconnect Tool Storage Location; STC Assembly Action; Basic Instructions - Snap-To-Connect (STC) Hydraulic Connectors

INTRODUCTION
Basicinstructions-Snap-to-Connect(STC®)hydraulicconnectors
WARNING
Escapinguid!
Relieveallpressurebeforeyoudisconnectuidlinesorperformworkonthehydraulicsystem.Make
surethatallcomponentsareingoodconditionandthatallconnectionsaresecurebeforeyoupres-
surizethesystem.DONOTuseyourhandtocheckforleaks.Useapieceofcardboardorpaper.
Failuretocomplycouldresultindeathorseriousinjury.
W1530A
NOTE:Dependingonthedateofmanufacture,yourTractorLoaderBackhoes(TLB)hydraulicandsteeringsystems
mayhaveSTC®connectorsthatattachtosystemcomponents.NotallconnectorsinthesesystemswillbeSTC®
connectors.STC®connectorsdonotrequiretighteningoratorquespecicationbutwillrequiretheuseofatoolto
disconnect.
STC®disconnecttoolstoragelocation
Thetool(1)ismountedtotheright-handchassisupright
insidetheenginecompartment.
RAIL17TLB0498BA1
RAIL17TLB0464AA2
STC®assemblyaction
Themaleconnector(D)insertsintothefemaleconnec-
tor(A).Themaleshoulder(C)spreadsthelatchring(B)
open.
RAIL17TLB0020AA3
