2000-13
STEP 60
BD06F118
Connect the wiring to the alternator. Remove and
discard tags.
STEP 61
BD06F117
If loader is equipped with air conditioning, mount the
compressor using the three mounting bolts (2),
connect the engine wiring harness connectors to air
compressor clutch connector (1). Remove and
discard tags.
STEP 62
BD06F116
Install lower cooler hose to the engine and tighten the
clamps to a torque of 10.1 to 11.3 Nm (90 to 100
lb-inch).
STEP 63
BD06F115
Install the drive belt.
STEP 64
BD06F113
BD06F114
Install the cover mounting brackets to the machine
frame. Install the belt cover, install the four mounting
bolts for the belt cover.
