76217
FEED PUMP
The pump is driven by a gear mating the camshaft’s one.
Direction of rotary: Left
Definition of dir. of rotation “Left” means anticlockwise
when looking from t h e drive
end
The low pressure system must be bleed
Ambient temperature from −40º to +120ºC
Oil fill quantity 0.45 liters engine o il
Figura 8
E NG I NE S SECTION 2 − FEED 11
ED. FEBUARY 2003
