Figure 190
Figure 191
76150
Figure 192
- Fix the LDA pipeline (1) to the engine head and to the
feed pump.
- Fix the pipes to the injectors throughout the brackets
previously assembled (fixing screw 1, Figure 190 and 2,
Figure 191).
76148
- Assemble lubr ication pipes to feed pump.
76132
Figure 193
76139
SECTION 3 − DUTY − INDUSTRIAL APPLICATION E NG I NE S
61
ED. FEBUARY 2003
