4 - 16
DIAGNOSTIC - SELECTION
CASE TRAINING CENTER
AUGUST 2000
EXCAVATOR MODEL SELECTION PROCEDURE
The model of excavator is selected after reinitialising
the machine code or replacing an electronic control
box.
1. Starter key switch ON, the screen below appears
and "?" for machine is selected:
2. Press the travel mode switch until the required
machine code is displayed.
3. Press the work mode switch. The screen below
appears and "?" for territory is selected.
4. Press the travel mode switch until the required
destination code is displayed.
5. Press the work mode switch. The screen below
appears and "?" for language is selected.
6. Press the travel mode switch to display the required
language:
0 = Japanese
1 = English
2 = Thai
3 = Chinese
4 = German
5 = French
6 = Italian
7 = Spanish
8 = Portuguese
9 = Dutch
10 = Danish
11 = Norwegian
12 = Swedish
13 = Finnish
14 = Icons
Example:
The screen above corresponds to a CX130 model
excavator for Europe in French.
MACHINE CODE MACHINE MODEL
SH0120 CX130
SH0150 Not used
SH0180 Not used
SH0200 CX210
SH0220 Not used
SH0250 Not used
SH0300 Not used
SH0400 Not used
SH0800 Not used
MACHINE : SH ? - 3
TERRITORY : ? LANGUAGE : ?
CONT. P / N KHR2669
MACHINE : SH0120- 3
TERRITORY : ? LANGUAGE : ?
CONT. P / N KHR2669
MACHINE : SH0120- 3
TERRITORY : ? LANGUAGE : ?
CONT. P / N KHR2669
Destination
code
destination
Pressure
unit
T° unit
3 EUROPE MPa °C
4 Rest of world KgF °C
MACHINE : SH0120- 3
TERRITORY : 3 LANGUAGE : ?
CONT. P / N KHR2669
MACHINE : SH0120- 3
TERRITORY : 3 LANGUAGE : 5
CONT. P / N KHR2669
