ELECTRIC CIRCUIT
5 - 8
CASE TRAINING CENTER
AUGUST 2000
1. Horn switch
2. Controls cancellation lever contact switch
3. Switch for hammer/grab
4. Door contact switch
5. Overload indicator switch
6. Air conditioner
7. Fuse box
8. Main electronic control box
9. Engine electronic control box
10. Rotary light relay
11. Engine emergency stop relay
12. Working lights relay
13. Horn relay
14. Pre-heat plug relay
15. DC-DC converter (24 V - 12 V)
16. Solar radiation detector
17. Radio
18. Cigarette lighter
19. Air conditioning control
20. Starting contact switch
21. Throttle control
22. Instrument panel
23. Engine idle control
24. Windshield contact switch
25. Windshield wiper motor electronic control box
26. Windshield wiper motor
27. Cab interior lighting
