1 - 18
GENERAL INFORMATION
CASE TRAINING CENTER
AUGUST 2000
PAGE
SERVICE POINTS
NB OF POINTS
INTERVALS IN HOURS
CLEAN
REPLACE
CHECK
GREASE
DRAIN
130/141 Hydraulic breaker (optional) 1 2/10/50
(A)
144 Engine oil level 1 10
148 Coolant level 1 10
155 Hydraulic reservoir level 1 10
177 Radiator and oil cooler 1 250 10
178 Fan/alternator belt tension 1 10/250
136 Attachment 18 50
139 Quick coupler (optional) 1 50
150 Drain fuel tank sediment 1 50
150 Drain water separator 1 50
164 Hydraulic system lines - 50
163 Return filter hydraulic breaker 1 100
156 Drain hydraulic reservoir sediment 1 250
166 Primary air filter element 1 250 (B) 1000 (C) 250 (B)
169 Swing reduction gear oil level 1 250
171 Travel reduction gears oil level 2 250
176 Pad screw torque - 250 (D)
176 Idler wheel and rollers - 250
195 Air conditioning (optional) - 250 250 (E)
200 Screw and nut torque - 250 (D)
204 Batteries electrolyte level 2 250
137 Turntable bearing 1 500
140 Turntable bearing teeth 1 500
145 Engine oil 1 500
145 Engine oil filters 2 500
151 Fuel filter 1 500
154 Hydraulic fluid condition 1 1000
157 Pilot filter 1 1000 (F)
160 Breather filter 1 1000
166 Secondary air filter element 1 1000 (G)
140/169 Swing reduction gear 1 5000 1000 (H)
172 Travel reduction gears 2 1000 (H)
157 Suction filter 1 2000 5000
158 Return filter 1 2000 (F)
159 Ultra clean filter 1 2000
160 Hydraulic fluid 1 10 000
75 Safety valves 2 (I)
148 Cooling circuit 1 (J)
173 Tracks 2 (K) (K)
180 Fuel tank filter 1 (K)
180 Machine inspection - (K) (K)
194 Fire extinguisher 1 (L)
