Case CX130 - Page 51

COMPONENTS CX130
3 - 17
CASE TRAINING CENTER
AUGUST 2000
Cushion cancellation
TO RETURN FILTER
TIROIR E
ORIFICE S
PRESSION DE PILOTAGE
TO HAND CONTROL
FROM CONTROL
TO RETURN FILTER
CUSHION SHUT-OFF SOLENOID VALVE
FROM HAND CONTROL
TO BOOM OR ARM SPOOL
SPOOL F
ORIFICES
ORIFICES
VALVE RETURN
