Case CX130 - Page 52

3 - 18
COMPONENTS CX130
CASE TRAINING CENTER
AUGUST 2000
Pump
Port name Port size
A
1, 2
Discharge port SAE 6000 psi 3/4"
S Intake port SAE 2500 psi 2 1/2"
T Drain port G 3/8
Pz
1
, z
2
Negative flow control pressure port G 1/4
X
3
, G
1, 2, 6, 7
Gauge port G 1/4
G
4
Gauge port G 3/8
X
8
Gear pump discharge s G 3/8
S Gear pump intake port
P
z2
G
2
Bleed plug
A
1
A
2
X
3
G
6
T
P
z1
G
7
H P PUMP
G
4
X
8
S
3
H P PUMP
G
1
PILOT
PRESURE
PUMP
