Case CX130 - Machine Condition Checks

4 - 2
DIAGNOSTIC - SELECTION
CASE TRAINING CENTER
AUGUST 2000
Machine condition
1. Machine condition CHK1
2a. Machine condition CHK2
Transistor output: 0 = OFF, 1 = ON
X: Not used
2b. Machine condition CHK5(was CHK2’)
In screen CHK2. when the travel mode switch is
pressed, the CHK2’ screen appears and windows TR1
and TR2 show any overloads in the corresponding
electrical circuits.
No overload = 0, Overload = 1
Example: In the screen opposite, windows TR1 and
TR2 show an overload on the swing brake and battery
relay circuit.
NOTE: In diagnostic mode, if an error code is changed
to zero, the data is also erased.
CHK MODE II H ENG 2000 rpm
1
P1 030.0 MPa I 0300 mA
P2 030.0 MPa WT 0080 C
N 03.00 MPa OT 0055 C
MODE: Travel - work
P1 Main pump pressure
P2 Main pump pressure
N Regulating pressure (N)
ENG: Engine speed
I Proportioning valve current
WT: Engine water temperature
OT: Hydraulic oil temperature
CHK MODE II H TR1 0000
2
R 0080 % TR2 0000
FT 0040 C TR3 0000
TV 0100 % TR4 0000
R: Engine load rate
FT: Fuel temperature
TV: Rate of acceleration
TR1 to TR3 Electronic control box transistor
outputs
TR4 Not used
TR10000 TR20000
TR30000
Swing brake Battery relay Beacon
Travel 2nd speed Shock absorption
X Swing pilot cancellation
Power boost X
CHK MODE II H TR1 0001
2
R 0080 % TR2 0001
FT 0040 °C TR3 0000
TV 0100 % TR4 0000
