DIAGNOSTIC - SELECTION
CASE TRAINING CENTER
AUGUST 2000
X = Not used
4. Machine condition CHK4
SW40000 SW50000 SW60000
Shock absorption Swing brake Windshield washer
X Emergency stop X
X Working lights Hammer mode
Engine idle Windshield wiper X
SW70000
Anti-theft
Starter motor switch
Overload indicator
X
CHK MODE I H TG 0000
4
FS 0080 BP 0000
AC 0005 SP1 0000
TR5 0010 SP2 0000
FS: Fuel gauge
AC: A/C control temperature
TR5: Electronic control box transistor
output (Not used)
TG: Engine speed
BP: Boom cylinder pressure
SP1 and SP2: Not used
AC 0004
1: below 30°C
2: between 30°C and 45°C
3: between 45°C and 65°C
4: between 65°C and 75°C
To Next Page
