Case CX130 - Failure Codes and Detection

DIAGNOSTIC - SELECTION
4 - 5
CASE TRAINING CENTER
AUGUST 2000
Diagnostic code
1. Detection of engine failures DIAG1
Failure code
Example: In the screen above, there is a defect in the engine water temperature sender.
2. Previous failures in the engine DIAG2
Example: The screen above shows that there is a defect in the electronic regulator rack position detector (0032)
and in the fuel temperature sender (0016).
DIAG MODE II H E 0000
1
E 0015 E 0000
E 0000 E 0000
E 0000 E 0000
E: Failure code
E0000: No defect
E0015: Engine water temperature sender
E0016: Fuel temperature sender
E0025: Fuel flow regulating resistance
E0031: Linear motor control circuit in electronic regulator
E0032: Electronic regulator rack position detector
E0041: Electronic regulator engine speed receiver
E0042: Engine speed detector
DIAG MODE II H E 0000
2
E 0032 E 0000
E 0016 E 0000
E 0000 E 0000
E: Failure code
