DIAGNOSTIC - SELECTION
4 - 9
CASE TRAINING CENTER
AUGUST 2000
5. Screen HR5, operating time of the various P2 pressures
6. Screen HR6, operating time of the various engine speeds
7. Screen HR7, operating time of the various engine water temperatures
8. Screen HR8, operating time of the various hydraulic oil temperatures
HR MODE II H 4 0000
5
1 0000 5 0000
2 0000 6 0000
3 0000 7 0000
1: 100 bar (10 MPa) or lower
2: Between 100 bar (10 MPa) and 150 bar
(15 MPa)
3: Between 150 bar (15 MPa) and 200 bar
(20 MPa)
4: Between 200 bar (20 MPa) and 250 bar
(25 MPa)
5: Between 250 bar (25 MPa) and 300 bar
(30 MPa)
6: Between 300 bar (30 MPa) and 350 bar
(35 MPa)
7: 350 bar (35 MPa) or above
HR MODE II H 4 0000
6
1 0000 5 0000
2 0000 6 0000
3 0000 7 0000
1: 1200 rpm or lower
2: Between 1200 rpm and 1400 rpm
3: Between 1400 rpm and 1600 rpm
4: Between 1600 rpm and 1800 rpm
5: Between 1800 rpm and 2000 rpm
6: Between 2000 rpm and 2200 rpm
7: 2200 rpm or higher
HR MODE II H 4 0000
7
1 0000 5 0000
2 0000 6 0000
3 0000 7 0000
1: 77°C or lower (1st and 2nd bar)
2: 77°C to 82°C (3rd bar)
3: 82°C to 97°C (4th bar)
4: 97°C to 100°C (5th bar)
5: 100°C to 103°C (6th bar)
6: 103°C to 105°C (7th bar)
7: 105°C or higher (8th bar)
HR MODE II H 4 0000
8
1 0000 5 0000
2 0000 6 0000
3 0000 7 0000
1: 45°C or lower (1st and 2nd bar)
2: 45°C to 60°C (3rd bar)
3: 60°C to 80°C (4th bar)
4: 80°C to 88°C (5th bar)
5: 88°C to 95°C (6th bar)
6: 95°C to 98°C (7th bar)
7: 98°C or higher (8th bar)
