DIAGNOSTIC - SELECTION
4 - 11
CASE TRAINING CENTER
AUGUST 2000
Re-initialisation
1. Re-initialisation RST1
PA = Adjusting fuel injection pump 0 = OFF, 1 = ON
AU = Automatic power boost 0 = ON, 1 = OFF
NOTE: To select the various adjustment windows, press as many times as necessary on the audible warning
device stop switch (a window is selected when the item concerned changes from negative appearance to positive
appearance).
2. Setting engine speed for hammer option
A. Select window BRK .
B. Start the engine, then, using the throttle control, set
the required engine speed which is displayed in the
BRK window on screen RST 1.
C. To save the engine speed, press the work mode
switch for 10 seconds. The audible warning device
sounds when saving is completed.
D. Turn the starter key switch to the OFF position.
E. Check the engine speed on screen CHK1.
Example:
In the above screen, the engine speed for the hammer option is set at 1800 rpm.
RST MODE II H PA 0000
1
BRK 0000 rpm AU 0000
L/M 0000 rpm HLD 0000
AI 0000 sec OUT 0000
MODE: Travel mode - work mode
BRK: Setting engine speed for hammer option
L/M: Not used
AI: Adjusting timing of automatic return to
idle (from 1 to 30 seconds)
PA: Adjusting fuel injection pump
AU: Automatic power boost
HLD: Data management
OUT: Not used
HLD 0000
Mode auto (0 = Maintain previous data / 1 = Up-date data)
Work mode (0 = Maintain previous data / 1 = Up-date data)
Travel mode (0 = Maintain previous data / 1 = Up-date data)
Hourmeter maintenance (0 = ON, 1 = OFF)
RST MODE 2 H PA 0000
1
BRK 1800 rpm AU 0000
L/M 0000 rpm HLD 0000
AI 0000 sec OUT 0000
