CX230B (NLC type, articulated boom)
Articulated boom
Standard arm Su-Short arm Short arm
Arm (dipper) length
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Boom length (articulated boom spec.)
5670 mm
223.23in
Bucket radius
1450 mm
57.09 in
Bucket wrist angle 177°
Maximum digging radius
9910 mm
390.16 in
8950 mm
352.36 in
9420 mm
370.87 in
Maximum digging radius at ground line
9720 mm
382.68 in
8750 mm
344.49 in
9230 mm
363.38 in
Maximum digging depth
6290 mm
247.64 in
5280 mm
207.87 in
5770 mm
227.16 in
Maximum vertical straight wall digging depth
5270 mm
207.48 in
4360 mm
171.65 in
4840 mm
190.55 in
Maximum digging height
10970 mm
431.89 in
10250 mm
403.54 in
10610 mm
417.72 in
Maximum dump height
8070 mm
317.72 in
7350 mm
289.37 in
7720 mm
303.94 in
Minimum swing radius at front
2310 mm
90.94 in
2460 mm
96.85 in
2630 mm
103.54 in
Height for minimum swing radius at front
8310 mm
327.16 in
8360 mm
329.13 in
8350 mm
328.74 in
