Issued 09-2014
1002-29
CX240B (LC, NLC type)
Standard boom
Standard arm Short arm Long arm
Arm (dipper) length
3000 mm
(118.11 in)
2500 mm
(98.42 in)
3520 mm
(138.58 in)
Boom length (Articulated boom spec.)
5850 mm
230.31 in
Bucket radius
1570 mm
61.81 in
Bucket wrist angle 175°
Maximum digging radius
10280 mm
404.72 in
9820 mm
386.61 in
10790 mm
424.80 in
Maximum digging radius at ground line
10100 mm
397.64 in
9630 mm
379.13 in
10620 mm
418.11 in
Maximum digging depth
6900 mm
271.65 in
6400 mm
251.97 in
7420 mm
292.13 in
Maximum vertical straight wall digging depth
6140 mm
241.73 in
5700 mm
224.41 in
6680 mm
262.99 in
Maximum digging height
9760 mm
384.25 in
9560 mm
376.38 in
10070 mm
396.46 in
Maximum dump height
6760 mm
266.14 in
6550 mm
257.87 in
7060 mm
277.95 in
Minimum swing radius at front
3950 mm
155.51 in
3980 mm
156.69 in
3950 mm
155.51 in
Height for minimum swing radius at front
7750 mm
305.12 in
7820 mm
307.87 in
7740 mm
304.72 in
