INTRODUCTION
Remotecontrolvalvecharacteristicdiagram
Operationremotecontrolvalvecontroldia-
gram
Ports1,3
A.
Secondarypressure[MPa(psi)]
B.
Pushrodstroke[mm(in)]
C.Operatingangle[deg.]
1
Secondarypressure
SMIL14CEX0416AB1
Ports2,4
A.
Secondarypressure[MPa(psi)]
B.
Pushrodstroke[mm(in)]
C.Operatingangle[deg.]
1
Secondarypressure
SMIL14CEX0418AB2
Travelremotecontrolvalvecontroldiagram
A.
Secondarypressure[MPa(psi)]
B.
Pushrodstroke[mm(in)]
C.
Pedaloperatingangle[deg.]
1
Secondarypressure
SMIL14CEX0423AB3
